Si1143 Gesture Sensor

Manufacturer: Parallax
Product Code: Sensors-Si1143_28046
Weight:0.25 lb
Reward Points:0
Out Of Stock
Price: $29.99

Compass Module 3-Axis Si1143.Compass Module 3-Axis Si1143 - bottom view.

The Si1143 Gesture Sensor is great for non-contact gesture recognition in microcontroller applications. By measuring infrared light levels from the three onboard IR LEDs, gestures in the up, down, left, right and center select directions can be detected.

Key Features:

  • Measures visible and IR ambient light levels, providing a range of operation from darkness to full sunlight.
  • Easy communication interface is compatible with any microcontroller.
  • Standard 0.1" header pins provide a convenient connection to breadboard or through-hole projects.

Application Ideas:

  • Touchless remote to control music or video.
  • Object detection for robotics and navigation.
  • Non-contact light switch controller.
  • Automatic faucet or equipment control for sanitary environments.


  • Voltage requirements: 3.0-5.5 VDC.
  • Current requirements: Less than 4 mA average.
  • Communication: I2C.
  • Dimensions: 2.0 x 2.28 x 0.22 in (5.08 x 5.79 x 0.48 cm).
  • Operating temp range: -40 to 185 °F (-40 to 85 °C).
